Catenary Idler Structure

An accommodating design that offers reliable and quick installation of structure.

PPI catenary structure incorporates a user-friendly design that allows for an easy assembly and tear down that lets the operator reconfigure their conveyor as the mining process dictates. The floor stands  are equipped with chain-slot brackets, this allows roof or floor mount configurations based on specific terrains at the mine.

  Reveal More
  • Catenary Idler Structure
  Click Image to Zoom

Popular Connections With:

Before
After
  • Integrated roof hangers allow for a chain mount when the surface below does not permit
  • Quick locking connection makes assembly and disassembly efficient
  • Adjustable legs enable the structure to be set up on uneven surfaces
  • Oversized handles on both the troughing idlers and returns make handling effortless, even with gloves
  • Gusseted frames ensure the frames will stand the test of time, even after many moves
  • Heavy duty galvanized stringers
  • Stand-alone structure utilizing PPI’s trusted roll design
  • Available in CEMA C, D and E for 24” - 60” belt widths.
