Stretch-Rite®

A two-part program simplifying the take-up system.

PPI’s Stretch-Rite® is a two-part program that allows customers to use a simpler manual take-up frame on long conveyors that have historically used more complicated automatic take-up systems. The program consists of the Stretch-Rite belt calculations and the optional 120” extended take-up. These extended take-ups can also be used on conveyors that have automatic take-up systems but require additional belt storage.

  Reveal More
  • Stretch-Rite Program
  Click Image to Zoom

Popular Connections With:

Before
After
  • Lower cost than gravity or hydraulic take-up systems
  • Less complicated than automatic take-up systems
  • Less space required than gravity take-up systems
  • Provides better understanding of the belt tension and stretch than the standard CEMA equations
  • Increased safety over a gravity take-up as there are no heavy counterweights to handle
  • Ability to analyze belts up to 2000 feet in length
  • Designed for belts up to 1000 PIW
  • Necessary pulleys and idlers are calculated and totaled to make ordering easier
  • Works with all manual take-up frames
